Suitable for buildings such as art galleries, museums, exhibition centers, science and technology museums, landscape buildings, etc.
| Generated Spec. | Imitation Stone Solar Panel | ||
| Model | COM-S1-270W | COM-S1-260W | COM-S1-250W |
| Power Max(W) | 270 | 260 | 250 |
| Power Torlance | ±3 | ±3 | ±3 |
| Vmpp(V) | 137.2 | 133.1 | 129.3 |
| Impp(A) | 2.01 | 2 | 1.98 |
| Voc(V) | 179 | 178 | 173.8 |
| Isc(A) | 2.26 | 2.26 | 2.26 |
| Maximum system voltage | 1500V | ||
| Reverse Current tolerance threshold | 3.5A | ||
| Working enviroment Tmp | -40℃~85℃ | ||
| Maximum load | 2400Pa/5400Pa | ||
| Protection level | P67 | ||
| Glass Size(mm) | 1600*1200 mm | ||
| Glass Thickness (mm) | 17mm | ||
| Glass with Encapsulation material Thickness | 37mm（With junction box） | ||
| Weight(Kg） | 74Kg | ||
| Wire | 2.5㎟, 1000mm | ||
| Bypass diode | HY6A10S | ||
| Product Structure | Glass 6mm+3.2mm+6mm | ||
| Front Glass | 6mm ultra clear rolled glass | ||
| Air thickness | - | ||
| Back glass | 6mm white tempered glass | ||
| Temperature Coefficient | |||
| NMOT | 42.3±2℃ | ||
| Pmax | -0.189%/℃ | ||
| Voc | -0.396%/℃ | ||
| Isc | +0.061%/℃ | ||
